Smart Rumen Bolus for Sheep Monitoring
-
LoRaWAN Compliant
-
Communication range up to 500 Meters
-
Battery life up to 2~3 years
-
Real time measuring the rumen temperature, movement and activity
-
IP68 Rugged Housing,food grade material, compact size 51mm×20..5mm
Description
JS0050 is a LoRaWAN compliant rumen bolus designed to capture sheep
activity, rumen temperature and movement. The material of the bolus is eco-friendly and
causes no harm to the sheep. Once inserted into a sheep by a standard bolus gun, the bolus
will remain in the rumen, All data is transmitted automatically first to the LoRa Base
Station and then to a cloud-based platform, which allows farmers, vets, and scientists to
process the information and deal with unexpected issues anytime, anywhere.
The earlier you detect health problems, the earlier you can react and reduce severe courses of diseases on your farm. Allow farmers to maximize the efficiency of farms.
The earlier you detect health problems, the earlier you can react and reduce severe courses of diseases on your farm. Allow farmers to maximize the efficiency of farms.
Specification
Parameters | Specification |
Modem | LoRaWAN |
Frequency | CN470Mhz, EU868 Mhz, US915 Mhz, AS923 Mhz |
Tx Power | Type(SF9):16dBm@470MHz;17dBm@868MHz;15dBm@915MHz;15dBm@923MHz |
Communication range | About 200 meters LoS (inserted into the rumen) |
Temperature accuracy | +/- 0.1°C |
Accelerometer | Monitoring the movement/actiity of rumen |
Reporting interval | 30mins by defualt, Configurable |
Average power consumption | <3.3mW |
Battery | 3V 1000mAh |
Battery life | 3 years |
Casing | IP68 |
Operation temperature | 21~45°C |
Storage Temperature | -40°C~20°C |
Dimensions | 51*20.5mm |
Weight | 40g |
Certification | RoHs Compliant, GB4806.7 standard food grade casing. |
Package | 20PCS/Giftbox, 400pcs/CTN |
